clava

Project Url: specs-feup/clava
Introduction: C/C++ Source-to-Source Tool based on Clang
More: Author   ReportBugs
Tags:

Clava is a C/C++/CUDA/OpenCL source-to-source compiler. It applies analysis and transformations written in LARA scripts (which is based on JavaScript), and can be installed in under a minute.

If you have used Clava, please consider filling the Clava User Experience Feedback form (it's short, really!)

Quickstart

Clava Tutorial - 2018 PACT - Tutorial on how to use Clava (recommended parts 1-3).

LARA Reference Guide - Start using LARA with examples.

Language Specification - List of all join points, attributes and actions available in Clava.

API Documentation - List of LARA APIs available in Clava.

API Slides - Introduction to Clava and the LARA Framework APIs.

For a sample of Clava examples, please check the Unit Tests.

Resources

A ZIP file with the compiled JAR for Clava can be downloaded from here.

There is an installation script for Linux that can be run locally and that will install the Clava binary in the script path (sudo is required for CMake module installation).

For an online demo version of Clava, please click here.

To call Clava from within CMake, please click here.

To build Clava, please check the ClavaWeaver project folder.

Running Clava

Clava can be run from CMake, using a GUI, or as a command-line tool.

CMake

Instructions for the Clava CMake plugin can be found here.

GUI

Run the JAR with passing parameters, e.g.:

java -jar Clava.jar

A video demonstrating the GUI can be found here.

Command Line

There are two main modes in command line, either passing all arguments (LARA file, parameters, etc...), or passing a configuration file that was built with the graphical user interface.

Using parameters:

java -jar Clava.jar <aspect.lara> -p <source_folder>

where is the LARA aspect you want to execute, and is the folder where the source code is.

There are more command-line options available, which can be consulted by running:

java -jar Clava.jar --help

Configuration file:

To pass a configuration file, use the flag -c:

java -jar Clava.jar -c <config.clava>

where is the configuration file created with the GUI.

Server Mode

For short executions, most of the execution time is related to starting a JVM.

There is an experimental feature where you can call Clava in server mode. In this mode, Clava can run in the background and will wait for requests. Then you can use a compiled program that performs requests to the server.

To start Clava in server mode, use the flag -server:

java -jar Clava.jar -server

The Linux instalation script provides the clavaw program, which sends a request to a Clava server:

    clavaw <Clava flags>

Limitations

  • Only absolute paths are supported in this mode, since the server will use its own folder as the working folder. However, files defined in config files should be handled automatically, they are converted to absolute paths, using the folder of the config file as the base folder. Additionally, if inside a Lara script you need to use files, you can use Clava.getData().getContextFolder() (import clava.Clava;) to return the folder of the config file.
  • The output of the program will appear on the terminal of the server, not where clavaw runs-

Troubleshooting

Error 'Invalid or corrupt jarfile'

Check if you have at least Java 11 installed, this is the minimum version.

Error 'missing libtinfo.so.5'

On Fedora >28 systems this can be solved by installing the package ncurses-compat-libs

Error 'cannot find -lz'

Install libz package (e.g., in Ubuntu sudo apt-get install libz-dev)

Citing Clava

If you want to reference Clava in your work, please use the following publication:

João Bispo, and João MP Cardoso. Clava: C/C++ source-to-source compilation using LARA. SoftwareX, Volume 12, 2020, Article 100565. [ScienceDirect] [bibtex]

Acknowledgments

This work has been partially funded by the ANTAREX project through the EU H2020 FET-HPC program under grant no. 671623. João Bispo acknowledges the support provided by Fundação para a Ciência e a Tecnologia, Portugal, under Post-Doctoral grant SFRH/BPD/118211/2016.

Contacts

João Bispo
